| 油圧図記号 | 種類 | ||||||||
|---|---|---|---|---|---|---|---|---|---|
 |
Direct-acting without reverse flow check | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SD-11A-30-Y-Z | 60 | 350 | 11A-3 |
| SD-2A-30-Y-Z | 120 | 350 | 2A-3 | ||||||
| SD-17A-30-Y-Z | 240 | 350 | 17A-3 | ||||||
| SD-19A-30-Y-Z | 480 | 350 | 19A-3 | ||||||
 |
Pilot-operated, balanced piston | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SP-163A-30-Y-Z | 30 | 350 | 163A-3 |
| SP-11A-30-Y-Z | 60 | 350 | 11A-3 | ||||||
| SP-2A-30-Y-Z | 120 | 350 | 2A-3 | ||||||
| SP-17A-30-Y-Z | 240 | 350 | 17A-3 | ||||||
| SP-19A-30-Y-Z | 480 | 350 | 19A-3 | ||||||
 |
Pilot-operated, balanced poppet | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SP-11A-3G-Y-Z | 60 | 350 | 11A-3 |
| SP-2A-3G-Y-Z | 120 | 350 | 2A-3 | ||||||
| SP-17A-3G-Y-Z | 240 | 350 | 17A-3 | ||||||
| SP-19A-3G-Y-Z | 480 | 350 | 19A-3 | ||||||
 |
Direct-acting, spool type | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SQ-08W-33-Y-Z | 15 | 240 | 08W-3 |
 |
Direct-acting, spool type | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SQ-08W-30-Y-Z | 22 | 240 | 08W-3 |
 |
Pilot-operated, kick-down | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SQ-163A-30-Y-Z | 30 | 350 | 163A-3 |
| SQ-11A-30-Y-Z | 60 | 350 | 11A-3 | ||||||
| SQ-2A-30-Y-Z | 120 | 350 | 2A-3 | ||||||
| SQ-17A-30-Y-Z | 240 | 350 | 17A-3 | ||||||
| SQ-19A-30-Y-Z | 480 | 350 | 19A-3 | ||||||
 |
Pilot-operated, balanced piston | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SQ-10W-30-Y-Z | 46 | 350 | 10W-3 |
 |
Pilot-operated, balanced piston | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SQ-10W-31-Y-Z | 46 | 350 | 10W-3 |
 |
Atmospherically referenced, direct-acting with reverse flow check | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | SC-11A-20-Y-Z | 60 | 350 | 11A-3 |
| SC-2A-20-Y-Z | 120 | 350 | 2A-3 | ||||||
| SC-17A-20-Y-Z | 240 | 350 | 17A-3 | ||||||
| SC-19A-20-Y-Z | 480 | 350 | 19A-3 | ||||||
 |
Ventable, pilot-operated, balanced poppet, main stage with integral 8A-2/08W-2 control cavity | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | RV-11A-3G-Y-8 | 60 | 350 | 11A-3 |
| RV-2A-3G-Y-Z | 120 | 350 | 2A-3 | ||||||
| RV-17A-3G-Y-Z | 240 | 350 | 17A-3 | ||||||
| RV-19A-3G-Y-Z | 480 | 350 | 19A-3 | ||||||
 |
Ventable, balanced piston relief, main stage with integral 8A control cavity | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | RV-11A-30-Y-8 | 60 | 350 | 11A-3 |
| RV-2A-30-Y-8 | 120 | 350 | 2A-3 | ||||||
| RV-17A-30-Y-8 | 240 | 350 | 17A-3 | ||||||
| RV-19A-30-Y-8 | 480 | 350 | 19A-3 | ||||||
 |
Ventable, pilot-operated, balanced piston with external drain with integral 8A control cavity | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | RV-21A-40-Y-8 | 60 | 350 | 21A-4 |
| RV-22A-40-Y-8 | 120 | 350 | 22A-4 | ||||||
| RV-23A-40-Y-8 | 240 | 350 | 23A-4 | ||||||
 |
Pilot-operated, balanced poppet relief with reverse flow check, main stage with integral 8A control cavity | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | RC-10A-2G-Y-8 | 95 | 350 | 10A-2 |
| RC-3A-2G-Y-8 | 200 | 350 | 3A-2 | ||||||
 |
Pilot-operated, balanced piston relief, main stage with integral 8A control cavity | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | RP-18A-20-Y-Z-76 | 760 | 350 | 18A-2 |
 |
Pilot-operated, balanced poppet relief, main stage with integral 8A control cavity | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | RP-10A-2G-Y-8 | 95 | 350 | 10A-2 |
| RP-3A-2G-Y-8 | 200 | 350 | 3A-2 | ||||||
| RP-16A-2G-Y-8 | 380 | 350 | 16A-2 | ||||||
| RP-18A-2G-Y-8 | 760 | 350 | 18A-2 | ||||||
 |
Pilot-operated, balanced piston relief, main stage with integral 8A control cavity | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | RP-10W-X-Y-8 | 95 | 350 | 10W-2 |
| RP-22MA-2S-Y-8 | 95 | 350 | 22MA-2 | ||||||
| RP-10A-20-Y-8 | 95 | 350 | 10A-2 | ||||||
| RP-3A-20-Y-8 | 200 | 350 | 3A-2 | ||||||
| RP-16A-20-Y-8 | 380 | 350 | 16A-2 | ||||||
| RP-18A-20-Y-Z | 760 | 350 | 18A-2 | ||||||
 |
Pilot-operated standard balanced, low pressure with no command | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | PRP-08W-2C-Y-Z-B1 | 30 | 350 | 08W-2 |
| PRP-10W-2C-Y-Z-B | 95 | 350 | 10W-2 | ||||||
| PRP-10A-2C-Y-Z-B | 95 | 350 | 10A-2 | ||||||
| PRP-10W-2D-Y-Z-B1 | 95 | 350 | 10W-2 | ||||||
| PRP-10W-2C-Y-Z-B1 | 95 | 350 | 10W-2 | ||||||
 |
Standard direct-acting, low pressure with no command | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | PRB-8A-2D-Y-Z | 1 | 350 | 8A-2 |
| PRB-8A-2C-Y-Z | 1 | 350 | 8A-2 | ||||||
| PRB-08W-2C-Y-Z | 1 | 350 | 08W-2 | ||||||
 |
Inverse direct-acting, high pressure setting with no command | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | PRA-8A-2D-Y-Z-74 | 1 | 350 | 8A-2 |
| PRA-8A-2C-Y-Z | 1 | 350 | 8A-2 | ||||||
| PRA-08W-2C-Y-Z | 1 | 350 | 08W-2 | ||||||
 |
Pilot-operated inverse balanced, high pressure setting with no command | 注文番号 | 流量(l/min) | 圧力(bar) | キャビティ | PRP-08W-2C-Y-Z-A1 | 30 | 240 | 08W-2 |
| PRP-10W-2C-Y-Z-A1 | 95 | 350 | 10W-2 |
